Đặc trưng
●Plug and play, integrated auto detecting, auto configuration, and auto firmware upgrade technology.
●Full compliance to IEEE 802.3ah specification OAM function.
●Support rich VLAN, DHCP Server and IGMP snooping multicast feature.
●Advantage traffic management
●Advanced Dynamic Bandwidth Allocation (DBA)
●The WAN port supports bridge or router mode.
●Advanced L2 features QinQ VLAN QoS support.
●Support NAT, Firewall function.
●Support Console/ Telnet/ NMS management interface for ease of operation and maintenance.
●Support 2K MAC address table.
●Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset
Sự chỉ rõ
PON interface | 1 G/EPON port(EPON PX20 plus and GPON Class B plus ) |
Bước sóng | Tx1310nm, Rx 1490nm, CATV 1550nm. |
Nhạy cảm | <> |
Quá tải | > -3dBm(PX20 plus ). |
Optical interface | 1 PON interface, 1 CATV interface, SC/APC connector |
LAN interface | 110/100/1000Mbps auto adaptive Ethernet interfaces Full/Half. RJ45 connector. |
RF interface | 1 RF output interface. |
DẪN ĐẾN | 9, For Status of POWER, LOS, PON, GE, CATV . |
Operating condition | Temperature: -5 degree -55 degree |
Storing condition | Temperature :-30 degree -60 degree |
Power supply | DC 12V |
Power consumption | Nhỏ hơn hoặc bằng 10W |
Kích thước | 110mm90mm25mm（LWH） |
Network Construction
Thông tin đặt hàng
| Product Name | Product Model | Descriptions |
| XPON ONU | CATV E/GPON ONU | 1GE Ethernet interface, 1 E/GPON interface, plastic casing, 1RF CATV,external power supply adapter DC 12V 1A |
Chú phổ biến: ftth xpon 1ge plus catv onu, Trung Quốc, nhà sản xuất, nhà cung cấp, nhà máy, tùy chỉnh, mua, giá, số lượng lớn, thương hiệu tương thích
